Quick Specs - Louvers
| Name | EA-725-D |
|---|---|
| Specifier Name(s) | EA725D |
| Avaliability | Unavailable |
| Free Area | 7.22 SqFt, 45.10%, 45.12(calc) |
| Blade Angle | Chevron |
| Name | Chevron Blade |
| Material Options | Extruded Aluminum, or Extruded Aluminum 6063 Alloy |
| Blade Orientation | Horizontal |
| Drainable Blade | Yes |
| Panel Minimum Size(s) | W: 12"x H: 12" |
| Panel Maximum Size(s) | W: 120"x H: 120" |
| Pressure Drop | .34 in. w.g. @ 1000 fpm |
| Water Penetration (fpm) | 1187 (fpm) |
Detailed Specs
*For additional options/configurations see spec sheet or contact the factory.
*This info listed here is For Reference ONLY, Please Refer to the Submittal For Full Product Data
