Page 3 of 10 (310 Results, 235 Groups)

12 Per Page 24 Per Page 60 Per Page 120 Per Page

75

7.5" Deep Round Aluminum Damper

75

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

1 in Group Compare

80

7.5" Deep Round Stainless Steel Damper

80

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

1 in Group Compare

85

6.5" Deep Aluminum Pin-Lock Control Damper with Transition

85

Maximum Velocity (FPM): 2000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .012 in. w.g. @ 1000 fpm

1 in Group Compare

850

4" Deep Aluminum Teardrop Blade Backdraft Damper

850

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 8 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

1 in Group Compare

900

10" Deep Aluminum Teardrop Blade Backdraft Damper

900

Maximum Velocity (FPM): 1000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .075 in. w.g. @ 1000 fpm

1 in Group Compare

A1

Class I Single Thickness Blade Smoke Damper

Arrow - A1_slice

A1H250, A1H350, A1H25034, A1H35034

UL Leakage Rating: Class I
Maximum Velocity (FPM): 2000 fpm

2 in Group Compare

A1(SS)

Class I Single Thickness Blade Stainless Steel Smoke Damper

Arrow - A1SS_slice

A1(SS)H250

UL Leakage Rating: Class I
Maximum Velocity (FPM): 3000 fpm

1 in Group Compare

A2

Class II Single Thickness Blade Smoke Damper

A2H25034, A2H250, A2H350

UL Leakage Rating: Class II
Maximum Velocity (FPM): 2000 fpm

2 in Group Compare

A2(SS)

Class II Single Thickness Blade Stainless Steel Smoke Damper

A2(SS)H250

UL Leakage Rating: Class II
Maximum Velocity (FPM): 3000 fpm

1 in Group Compare

A89

Uninsulated Static Rectangular Ceiling Radiation Damper

A89

Insulation: Uninsulated
Single Panel Product Max Sizes: W: 18"x H: 10", When Horizontally Mounted

1 in Group Compare

A91

Insulated Static Rectangular Ceiling Radiation Damper

A91

Insulation: Insulated (unspecified)
Single Panel Product Max Sizes: W: 18"x H: 18", When Horizontally Mounted

1 in Group Compare

A93

Insulated Dual Opening Static Ceiling Radiation Damper

A93

Insulation: Insulated (unspecified)
Single Panel Product Max Sizes: W: 24"x H: 24", When Horizontally Mounted

1 in Group Compare

A95

Uninsulated Static Round Ceiling Radiation Damper

A95

Insulation: Uninsulated
Single Panel Product Max Sizes: Diameter: 11", When Horizontally Mounted

1 in Group Compare

A97

Insulated Static Round Ceiling Radiation Damper

A97

Insulation: Insulated (unspecified)
Single Panel Product Max Sizes: Diameter: 20", When Horizontally Mounted

1 in Group Compare

AA1

Class I Airfoil Blade Smoke Damper

AA1H250, AA1H350, AA1H25034, AA1H35034, AA1H25044, AA1H35044, AA1H25046, AA1H35046

UL Leakage Rating: Class I
Maximum Velocity (FPM): 2000 fpm

4 in Group Compare

AA2

Class II Airfoil Blade Smoke Damper

AA2H250, AA2H350, AA2H25034, AA2H35034, AA2H25044, AA2H35044, AA2H25046, AA2H35046

UL Leakage Rating: Class II
Maximum Velocity (FPM): 2000 fpm

4 in Group Compare

AA2M

Class II Airfoil Blade Modulating Smoke Damper

AA2M

UL Leakage Rating: Class II
Maximum Velocity (FPM): 2000 fpm

1 in Group Compare

AC482-12-12

12" Deep Aluminum or Steel Acoustical Louver with 12" On Center Blade Spacing

Arrow - AC482-12

AC48212

Free Area %: 25%
Pressure Drop: .1 in. w.g. @ 1000 fpm
Water Penetration (fpm): 1057 (fpm)

1 in Group Compare

AC482-12-6

12" Deep Aluminum or Steel Acoustical Louver with 6" On Center Blade Spacing

Arrow - AC482-12-6

AC482126

Free Area %: 24.88%
Pressure Drop: .07 in. w.g. @ 1000 fpm
Water Penetration (fpm): 1084 (fpm)

1 in Group Compare

AC482-6-6

6" Deep Aluminum or Steel Acoustical Louver with 6" On Center Blade Spacing

Arrow - AC482-6-6

AC48266

Free Area %: 26%
Pressure Drop: .1 in. w.g. @ 1000 fpm
Water Penetration (fpm): 858 (fpm)

1 in Group Compare

AC482-8-8

8" Deep Aluminum or Steel Acoustical Louver with 8" On Center Blade Spacing

Arrow - AC482-8-8

AC48288

Free Area %: 25%
Pressure Drop: .085 in. w.g. @ 1000 fpm
Water Penetration (fpm): 990 (fpm)

1 in Group Compare

AF-206/207

5" Deep Aluminum Airfoil Blade Damper

Arrow - AF-206-AF-207

206, 207

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .04 in. w.g. @ 1000 fpm

2 in Group Compare

AFD-20

5" Deep Ultra Low Leak Airfoil Control Damper

AFD20

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

1 in Group Compare

AFDTI-25

5" Deep Ultra Low Leak Insulated Airfoil Control Damper

Arrow - AFDTI-25

AFDTI25

Maximum Velocity (FPM): 3000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .04 in. w.g. @ 1000 fpm

1 in Group Compare

Page 3 of 10 (310 Results, 235 Groups)
